692
MDF930X ACTIVE MAGNETIC DIRECTIO
NOVA Part#:
432-1405226-692
Manufacturer:
Manufacturer Part No:
692
Standard Package:
1
Technical Datasheet:
Available download format
Please fill in your information in the form , we will contact you and give you the cad model as soon as possible.
15.0045MHz - Directional Antenna RF Antenna 9kHz ~ 30MHz - SMA Female Magnetic
| Category | RF Antennas | |
| Manufacturer | Visual Communications Company - VCC | |
| RoHS | 1 | |
| Mounting Type | Magnetic | |
| Series | - | |
| Frequency Group | VHF (f < 300MHz) | |
| Frequency (Center/Band) | 15.0045MHz | |
| Number of Bands | 1 | |
| VSWR | - | |
| Frequency Range | 9kHz ~ 30MHz | |
| Return Loss | - | |
| RF Family/Standard | - | |
| Gain | - | |
| Antenna Type | Directional Antenna | |
| Termination | SMA Female | |
| Features | - | |
| Ingress Protection | - | |
| Power - Max | 5 W | |
| Applications | - | |
| Height (Max) | 7.087" (180.00mm) | |
| Other Names | 3959-692 |
In stock Please contact us
Not the price you want? Fill the forms and we'll contact you ASAP.
